Massive 500m Range & 400-Channel Agility: Unshakeable signal stability with an impressive 300–500m line-of-sight range. 400 user-adjustable UHF channels (100 per receiver) ensure interference-free operation for up to 20 simultaneous systems (80 mics).
Professional 4-Channel True Diversity Receiver: Sleek 1U rack-mountable console features dual large LED displays, 4 separate SQ potentiometers, 4 balanced XLR outputs, and 1 mixed output for seamless integration with any PA system.
Premium KSM8 Handheld Mics with Blue Status Ring: High-fidelity unidirectional condenser capsules deliver exact sound restoration from 40Hz–20kHz. Patented housing includes a signature blue LED ring for at-a-glance status monitoring and runs up to 12 hours on AA batteries.
Pristine Digital Audio & Anti-Interference: Advanced PLL digital synthesis ensures ±0.001% frequency stability. Achieves >60dB SNR,
4× KSM8 Handheld Mics | 400 Channels | 300-500m Range | True Diversity | PLL Digital Synthesis
Click images to enlarge. Actual product may vary slightly.
The AD4Q 4-Channel UHF Digital Wireless Microphone System is a flagship professional wireless solution engineered for large-scale events and demanding live audio environments. Designed specifically for stage performances, band gigs, houses of worship, school auditoriums, and corporate conference rooms, this system includes a sleek 1U rack-mountable receiver and 4 premium KSM8 handheld condenser microphones. Featuring 400 user-adjustable UHF channels (100 per receiver), PLL digital phase-locked loop technology, and an impressive 300–500 meter line-of-sight range, the AD4Q delivers pristine, dropout-free audio that competitors simply cannot match at this price point. Each mic runs up to 12 hours on AA batteries, with a signature blue LED status ring for real-time monitoring—making this the ultimate all-in-one wireless solution for any professional audio setup.[reference:0]
Each of the 4 independent receivers offers 100 selectable channels (250 kHz spacing, 24.75 MHz per channel), totaling 400 user-adjustable UHF frequencies across the 610–670 MHz band. Up to 20 systems (80 transmitters) can operate simultaneously on the same stage without crosstalk, making this ideal for large-scale musicals, multi-act festivals, and multi-room conference centers.[reference:1]
Each KSM8 handheld features a high-fidelity unidirectional (cardioid) condenser capsule with a frequency response of 40 Hz – 20 kHz, capturing every vocal nuance with outstanding clarity and minimal noise. Rated at -43 ±3dB sensitivity @ 1 kHz with only 80 mA power consumption, each mic runs continuously for up to 12 hours on AA batteries. The patented housing includes a signature blue light ring that illuminates during operation for at-a-glance status monitoring on dark stages.[reference:3]
The rear panel features 4 independent SQ potentiometers, 4 balanced XLR outputs, and 1 mixed unbalanced output, providing full compatibility with mixers, amplifiers, and recording interfaces. Unlike fixed single-channel systems, each handheld can be paired across all 400 channels within two receiver banks, offering unmatched setup versatility for changing stage configurations or multi-room events.[reference:4]
The AD4Q ships as a turnkey solution with everything needed for immediate professional use: 1 × 4-channel digital receiver, 4 × KSM8 handheld microphones, 1 × 1/4-inch audio cable, 1 × universal AC-DC adapter (110V / 240V), 4 × antennas, and 1 × user manual. The receiver features dual large LED displays for real-time frequency monitoring and a sleek 1U rack-mountable form factor that integrates seamlessly into any existing audio rack setup.[reference:5]
| Parameter | Specification |
|---|---|
| System Configuration | 4-channel digital receiver + 4 × KSM8 handheld condenser mics |
| Frequency Range | UHF 610 – 670 MHz |
| Selectable Channels | 400 total (100 per receiver), 250 kHz spacing |
| Simultaneous Systems | Up to 20 systems (80 transmitters) in same venue |
| Operating Range | 300–500 meters (open area) / 80–200m (complex environment) |
| Frequency Stability | ±0.001% (PLL digital synthesis) |
| Modulation Mode | FM |
| S/N Ratio | > 60 dB |
| T.H.D. | < 0.5% @ 1 kHz |
| Dynamic Range | ≥ 100 dB |
| Receiver Sensitivity | 1.2μV @ S/N = 12dB |
| Receiver Audio Outputs | 4 × Balanced XLR (0–400mV) + 1 × Mixed Unbalanced (0–300mV) |
| Receiver Power Supply | DC 12V – 17V |
| Mic Capsule Type | Condenser (Capacitance), Unidirectional Cardioid |
| Mic Frequency Response | 40 Hz – 20 kHz |
| Mic Sensitivity | -43 ±3dB @ 1 kHz |
| Mic Battery Life | Up to 12 hours (3 × AA 1.5V batteries) |
| Mic Power Consumption | 80 mA |
| Special Feature | Blue LED status ring on each handheld mic |
| Warranty | 1 Year (Manufacturer: MiCWL Audio Inc.) |
If you have any questions about the AD4Q system, need a custom microphone capsule configuration (KSM9, Beta58, BeltPack options available), or would like to inquire about bulk / government orders — our team is ready to assist you.
